Battery Parameters

Module Energy

64W/280AH/17.92kWh

Number of Battery Module

12

Nominal System Energy

215kWh

Operating Voltage Rang

672-864V

Max Charge/Discharge Current

0.5C/0.5C

Battery Module Dimension&Weight

440*912*265mm(W*H*D)145kg

AC Parameters

Nominal Power

1004W

Nominal AC Voltage

400V

Nominal Frequency

50/60Hz

Grid Type

3W+N+PE/3W+PE

Max.Efficiency

97.3%(Peak

Max Load Capacity

110%(Continoues),120%(1min)

PV Parameters

Input Power

100kW

MPPT Voltage Range

200~650V(320-650V With Full load)

Max Input Current

320A

System Parameters

Cooling Mode

Air Conditioner

Noise

<70dB

IP Rating

IP54

Altitude

<2000m

Operating Temp.Range

-20℃-60℃

Allowed Humidity Range

595℃(RH)

Accessories

Smoke Sensor, Door Sensor, Water Sensor, Fire Suppression, EPO

Isolation Transformer

Optional

Communication

RS485/CAV4G/Dry contact

Design Certification

IEC63056,IEC62477-1,EC62109-1/2.GB/T36276,ICE62619,EN61000-6

Weight

Approx.3200kg

Dimension(W*D*H)

Approx.1850*1200*2300mm
