·Type approval by CCS.
·The modular design facilitates transportation, installation, system construction, operation,and maintenance.
·The integrate exhausted gas duct will reduce the risk of fire or explosion in the battery compartment.
·Battery string level thermal management: Air cooling/liquid cooling optional.
·C5 Enclosure anticorrosion class: Apply for inland river and ocean applications.
Item | Parameter | |
Cell | LF280 | LF310 |
Connection mode | 1P270S | 1P270S |
Nominal energy | 241.97kWh | 267.84kWh |
Battery string size | 1110*1054*3169(Liquid cooling) 1110*1054*2700(Air cooling) | 1110*1054*3169(Liquid cooling) 1110*1054*2700(Air cooling) |
Nominal capacity | 280Ah | 310Ah |
Maximum continuous charge/discharge current | 280A/280A | 310A/310A |
Nominal Voltage | 864VDC voltage range:783-945VDC | 864VDC voltage range:783-945VDC |
Weight | 2000±50kg | 2100±50kg |
Communication protocol | CAN/RS485 | CAN/RS485 |
Explosion-proof design | Explosion-proof breather valve | Explosion-proof breather valve |
Case material | Welding of square steel | Welding of square steel |
Protection degree | IP44 | IP44 |
Thermal management | Liquid cooling/heating | Liquid cooling/heating |
BMS | Integrated BMS | Integrated BMS |
Start mode | Local+remote startup | Local+remote startup |
Alarm | Buzzer | Buzzer |
