High C-rate:up to 3C.
Suitable for both China and abroad,meet design requirements ofthe mainstream classification society.
Efficient liquid cooling solution at battery string level.
C5 Enclosure anticorrosion class.
Apply for inand river and Marine applications.
| Item | Parameter |
| Cell | LF125P |
| Connection mode | 1P288S |
| Nominal energy | 115.92kWh |
| Battery string size | 1000*1000*2500 |
| Nominal capacity | 125Ah |
| Maximum continuous charge/discharge current | ≤375A |
| Nominal Voltage | 927.36VDC voltage range:835.2-1008VDC |
| Weight | 1240±50kg |
| Communication mode | CAN/RS485 |
| Explosion-proof design | Explosion-proof breath valve |
| Case material | Welding of square steel |
| Anticorrosion class | C5 |
| BMS | Integrated BMS |
| Thermal management | Double plate liquid cooling |
| Protection degree | IP44 |
| Start mode | Local+remote startup |
| Alarm | Buzzer |
